Pinout Reference for ATX 6-pin 12V Power Connectors Pin Name Color Description 1 COM Black Ground 2 COM Black Ground 3 COM Black Ground 4 +12VDC Yellow +12 VDC 5 +12VDC Yellow +12 VDC 6 +12VDC Yellow +12 VDC If you’re using this pinout table to test power supply voltages, be aware that the voltages must be within ATX specified tolerances. Tell us why! Other Not enough details Hard to understand Submit Get the Latest Tech News Delivered Every Day
#8 pin molex connector free
If you have a power supply that has two free 4-pin molex power connectors, but your video card requires a 6-pin 12V power connector, you can use an adapter. Some power supplies come with a 6+2 PCI Express power cable, which is a cable that has both a 6-pin power connector and an additional 2-pin power connector semi-attached, which can either be combined to become an 8-pin ATX cable or kept separate to work with 6-pin-only connections. Be sure to check your video card’s documentation to see if this 6-instead-of-8-pin configuration will work for you.
#8 pin molex connector full
Unfortunately, even though a smaller cable fits, some cards simply won’t work properly without the full power provided by an 8-pin connector. If this is the case, but you only have a 6-pin 12V power connector, a 6-pin one will fit but won’t provide any more than what the 6-pin provides. Video cards sometimes come with an 8-pin connector if they can utilize more power than what a 6-pin cable can provide. Some video cards, for example, draw more than 75 watts, in which case connecting a 6-pin 12V power cable can provide more power to the card. The 6-pin 12V power connector is used to power PCI Express expansion cards that require more power than their expansion slots can provide, which is 75 watts.
#8 pin molex connector how to
You can see other ATX power supply connector pinouts in our ATX Power Supply Pinout Tables list.Ģ:23 How to Test the Power Supply in a Computer Using an ATX 6-pin 12V Power Connector Pinout Reference for ATX 6-pin 12V Power Connectors Tim Fisher ATX 6-pin 12V Power Connector Pinout (ATX v2.2)īelow is the pinout for the standard ATX 6-pin (3×2) 12V power connector as of Version 2.2 of the ATX Specification (PDF). The terms “PCI Express cables” or “PEG cables” (for PCI Express Graphics) are sometimes used to describe a 6-pin 12V power connector. On motherboards, the more common connector used for this purpose is the ATX 4-pin Power Connector, used either by itself or with a second 4-pin connector, creating an 8-pin connector. This 6-pin connector is also sometimes used to provide extra power to high-end video cards.
The ATX 6-pin power supply connector is a motherboard power connector used to provide +12 VDC to the processor voltage regulator. Pinout for the ATX 6-pin (3×2) 12V Motherboard Power Connector
